Description
About this item:
The JHD 162A 16×2 LCD Display Module is a widely used alphanumeric display for embedded systems and DIY electronics. It provides a clear two-line, 16-character-per-line text display, making it suitable for projects that require simple and effective user interaction.
This module uses the industry-standard HD44780 controller, ensuring broad compatibility with Arduino, Raspberry Pi, microcontrollers, and development boards. It can be interfaced in either 4-bit or 8-bit parallel mode, requiring multiple I/O pins, or with an I2C adapter, which reduces the pin requirement to just two (SDA, SCL).
The display typically comes with a yellow-green LED backlight, though variants with blue or other colors are also available. It operates on 5V DC, making it easy to integrate into most digital circuits.
Key Specifications
-
Display Size: 16 characters × 2 rows
-
Controller IC: HD44780 (industry standard)
-
Operating Voltage: 5V DC
-
Interface: 4-bit / 8-bit parallel; I2C with adapter
-
Backlight: Yellow-green (standard), blue variants available
-
Character Format: Alphanumeric (ASCII characters + symbols)
Applications
-
Embedded systems & microcontroller projects
-
DIY electronics (Arduino, Raspberry Pi, ESP8266/ESP32)
-
Measuring instruments & industrial devices
-
Home automation displays
-
Educational kits and prototyping
